ibaHD-Server
Dati storici immediatamente disponibili
ibaHD-Server a colpo d’occhio
- Registrazione continua di dati per un lungo periodo di tempo
- Accesso diretto a dati storici al di fuori di ibaPDA
- Interfaccia intuitiva per visualizzare i dati storici, ad es. funzioni quali navigazione, scorrimento, salto a una certa data
- Funzione di zoom rapido per visualizzare una panoramica annuale, mensile o settimanale con una precisione al millisecondo
- Registrazione e visualizzazione di messaggi in base agli eventi
Visualization from the annual overview down to the milliseconds range
Thanks to the special storage principle for measurement data in ibaHD-Server, it is possible to display the measured signals over the entire acquisition period in one trend view in the ibaPDA client or in the trend view in ibaAnalyzer. With a simple zoom function, the displayed time section can be quickly resolved down to months, weeks, days or even milliseconds. Thus, suddenly occurring irregularities in a continuous process can be detected as well as slowly developing trend deviations.
One single server for more than one HD data store
One ibaHD-Server can be used for administrating more than one HD store. Both the time-based and length-based recording of signals as well as the recording of event messages are treated like the recording of a measurement file in ibaPDA.
Rapid Access to Events from the Past
Messages for product changes or noticeable process conditions can be defined as events and stored in the ibaHD-Server. The events are controlled by trigger conditions and they can be supplemented with information about the current state from text signals or directly from measurement signals from ibaPDA server.
Product Features
Continuous Data Recording over Long Periods of Time
Thanks to its ability to store measure ment data continuously over long periods of time, ibaHD- Server offers unique opportunities for analysis for different data and requirements as a central and open data platform.
Global database allows a comprehensive process image
This means that measurement signals from live processes together with values from post-processing are directly available in a global database over a long period of time and open up completely new analysis opportunities.
Time periods open new possibilities for storage and analysis
Time periods mark a time range within a time-based HD store, such as one process step, one shift, or one day. The start and end of the time periods can be specified using triggers or times.
Attach Additional Information Directly at the Origin Time
Pre-defined or free texts can be placed as annotations in the HD trend view. This means additional information can be documented with the correct time and also supplemented by images, PDF documents or other files.
User Management
To protect the data in ibaHD-Server against unauthorized access, the user management offers the possibility to assign authorizations to individual users.
Video Images Extend Analysis Options
The combination of historical data and video images expands the possibilities for analyzing processes or failures. Video images provide additional visual information wherever processes are difficult to measure or cannot be reliably detected by sensors.
All data for a process step available quickly and at a glance
Time periods are displayed in the ibaPDA client in the time period table that can be filtered. With specific queries, e.g. for certain time ranges or production data, suitable time periods can be found quickly and the associated signals and data can be analyzed efficiently.
More than saving data with backups
The backup function offers flexible options for individual backup strategies for HD stores. In this way, the data backup can be automated or manually done according to custom parameters.
License-free offline analysis with backups
Backups generated with ibaHD-Server can be read and analyzed with ibaAnalyzer for free without a license. In this way, you can analyze HD data independently of the productive system. Very long periods of time can also be analyzed with attached backups.
Simply Import Data Files
Measurement files in DAT format created with ibaPDA can be integrated into an HD store via an import process. For this purpose it is possible to import data files or entire data file directories into an HD store and measurement data can be entered with the correct time.
Convenient administration with ibaHD-Manager
The ibaHD-Manager is used for diagnostics, administration and configuration of the ibaHD-Server service as a central management tool.
Modular Product Design
The basic licenses for ibaHD-Server are graded according to the number of signals and comprise one ibaHD-Server, two HD data stores and two HD clients. One time period can be used with the basic license.
Automatic e-mail messages
Status messages from ibaHDServer can be sent immediately to defined recipients using the e-mail function. E-mails can be sent automatically by means of predefined trigger signals.
SNMP
ibaHD-Server has an integrated SNMP server and can be integrated into a company-wide network management system according to the SNMP protocol. SNMP protocols V1, V2c and V3 are supported.
Searching signal conditions
It is also possible to search signal conditions in any given time period and, for example, to find outliers and limit value exceedances.
Integration of ibaHD-Server in the iba System
Tailor-made analyses of HD data
Interactive analysis with ibaAnalyzer
Data from ibaHD-Server can be conveniently retrieved, displayed and analyzed with the ibaAnalyzer analysis program. It is just as easy to access HD data as it is to open a measurement file. The big advantage of ibaHD-Server is that the aggregated data can be displayed over a larger period of time than is possible with measurement files - for example over a week, a month or even longer period of time.
Automatically post-process HD data and extract information
HD data can be automatically processed with the software ibaDatCoordinator. A time period can be configured in ibaDatCoordinator for which the data from ibaHD-Server is to be read and processed. Based on the HD data, so-called offline events can also be generated or the data can be processed like measurement files, for example to calculate characteristic values (KPIs) and extract these KPIs into databases or to use them in reports.
Open data platform for any type of data analysis
Access to HD data with customer-specific systems
The product ibaHD-Server-V2-API-Read is a programming interface (API: Application Programming Interface) that can be used to query historical data and events from the HD stores by external systems.
Success Stories
Contattare il proprio partner commerciale locale.
Order no. | Name | Description |
---|---|---|
30.800064 | ibaHD-Server-64 | Basic license ibaHD-Server for 64 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.800128 | ibaHD-Server-128 | Basic license ibaHD-Server for 128 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.800256 | ibaHD-Server-256 | Basic license ibaHD-Server for 256 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.800512 | ibaHD-Server-512 | Basic license ibaHD-Server for 512 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.801024 | ibaHD-Server-1024 | Basic license ibaHD-Server for 1024 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.802048 | ibaHD-Server-2048 | Basic license ibaHD-Server for 2048 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.804096 | ibaHD-Server-4096 | Basic license ibaHD-Server for 4096 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.808192 | ibaHD-Server-8192 | Basic license ibaHD-Server for 8192 tags (signals), including 2 HD clients, 2 HD stores and 1 time period |
30.806666 | ibaHD-Server-unlimited | Basic license ibaHD-Server for unlimited number of tags, including 2 HD clients, 2 HD stores3 and 1 time period |
30.800003 | ibaHD-Server-One-Store | License extension HD-Server: 1 more HD data store (only with WIBU dongle) |
30.800004 | ibaHD-Server-Two-Stores | License extension HD-Server: 2 more HD data stores |
30.800005 | ibaHD-Server-Client | License extension ibaHD-Server: single client |
30.800006 | ibaHD-Server-Multi Client | License extension ibaHD-Server: 5 additional HD client interfaces |
30.800007 | ibaHD-Server-OPC-UA-Server+ | License extension for extended OPC UA server functionality |
30.800010 | ibaHD-Server Time Period | License extension for the definition of 2 time periods |
30.800011 | ibaHD-Server Ultra Time Period Store | License extension for the definition of 128 time periods |
30.820001 | Upgrade-HD-Server-64 to 128 | License extension ibaHD-Server: 64 tags to 128 tags |
30.820002 | Upgrade-HD-Server-128 to 256 | License extension ibaHD-Server: 128 tags to 256 tags |
30.820003 | Upgrade-HD-Server-256 to 512 | License extension ibaHD-Server: 256 tags to 512 tags |
30.820004 | Upgrade-HD-Server-512 to 1024 | License extension ibaHD-Server: 512 tags to 1024 tags |
30.820005 | Upgrade-HD-Server-1024 to 2048 | License extension ibaHD-Server: 1024 tags to 2048 tags |
30.820006 | Upgrade-HD-Server-2048 to 4096 | License extension ibaHD-Server: 2048 tags to 4096 tags |
30.820007 | Upgrade-HD-Server-4096 to 8192 | License extension ibaHD-Server: 4096 tags to 8192 tags |
30.820008 | Upgrade-HD-Server-8192 to unlimited | License extension ibaHD-Server: 8192 tags to unlimited tags |
30.800001 | ibaHD-Server-API-Read | gRPC-API interface to query saved signals and events from existing HD stores |
60.000007 | WIBU Software-Key | Generating a software key |
3 The number of tags that can be stored per HD store is limited to 65534.
The upgrade licenses 30.820001 to 30.820008 are supported from ibaHD-Server v3.0.0
